  • M9120
  • 512MB GDDR2
  • PCI Express x16
  • Brand Matrox
    Model M9120-E512F
    Interface  PCI Express x16
    Chipset Manufacturer matrox
    GPU  M9120
    Memory Size 512MB
    Memory Type  GDDR2
    3D API
    OpenGL  OpenGL 2.0
    DVI  2 x DVI-I
    Digital Resolution 1920 x 1200
    Analog Resolution 2048 x 1536
    Max Displays Per Board 2
    Cooler Fanless
    Operating Systems Supported Microsoft Windows 10 (32-bit, 64-bit; non-WHQL)
    Windows Server 2012 (32-bit, 64-bit)
    Windows 7 (32-bit, 64-bit)
    Windows Embedded Standard 7 (32-bit)
    Windows Vista (32-bit, 64-bit)
    Windows Server 2008 R1 (32-bit, 64-bit)
    Windows Server 2008 R2
    Windows XP (32-bit, 64-bit)
    Windows Server 2003 and Linux*
    * M-Series cards support a wide range of Linux operating systems.
    Features High-resolution dual monitor support
    Support resolutions up to 1920 x 1200 (Digital) and 2048 x 1536 (Analog) per output

    Native PCI express x16 performance
    Maximum bandwidth to ensure best performance

    512MB of memory
    For enhanced performance in demanding multi-monitor applications

    ATX form factor
    Passive cooling and low power consumption
    Fanless design eliminates noise and increases product reliability

    Stretched and independent desktop modes
    Expand your desktop across multiple monitors or set each monitor independent of each other

    Edge Overlap
    Easily and intuitively adjust the number of overlapping pixels to create a seamless, unified image on up to eight edge blending projectors

    M-Series multi-card support1
    Add an additional M-Series card into the same system to drive up to 10 displays from two cards

    Joined graphics card mode2
    Insert two M-Series cards into the same system to drive even more monitors across a stretched desktop

    Matrox Clone
    View a copy of one display on the other displays

    Wide enterprise flexibility
    Unified driver package compatible with other Matrox products

    Matrox PowerDesk software
    Easily configure and manage program windows on multiple monitors

    Multiple operating system support
    Display drivers for Microsoft Windows 10 (32-bit, 64-bit; non-WHQL), Windows Server 2012 (32-bit, 64-bit), Windows 7 (32-bit, 64-bit), Windows Embedded Standard 7 (32-bit), Windows Vista (32-bit, 64-bit), Windows Server 2008 R1 (32-bit, 64-bit), Windows Server 2008 R2, Windows XP (32-bit, 64-bit), Windows Server 2003 and Linux3

    1 Operating system, hardware and driver compatibility need to be verified for large monitor configuration arrays.
    2 Available only under Microsoft XP and Windows 7 XDDM mode when M9188 is the additional card.
    3 M-Series cards support a wide range of Linux operating systems.
    Form Factor & Dimensions
    Form Factor  ATX
    Dimensions (L x H) 6.60" x 4.38"
