Bus compatibility PCIe Gen3 x16

Power consumption 150 W

Form factor 248mm (L) x 110mm (H) single PCIe slot wide

Operating system Windows 7 (32/64-bit), Windows 8.1 (64-bit), Windows 10 (64-bit)

Platforms Intel and AMD architectures

Power Connector One 2x3 power connector

Graphics accelerator ATI FirePro TM

Display memory 8 GB GDDR5

Memory interface 256-bit

Memory bandwidth 160 GB/s

Pixel depth 32-bit pixels (supports 8-bit and 10-bit per color channel)

Electrical standard DisplayPort (DP) complying to v1.2
Direct 3D hardware support Microsoft DirectX v11.2, Vertex Shader 5.0, Pixel Shader 5.0

OpenGL hardware support OpenGL 4.4

OpenCL hardware support OpenCL 2.0

Connectors 4-DisplayPort (DP)

Supported resolutions Up to 5.8MP grayscale at full refresh rate (VGA at boot-up)

Approvals and compliance FCC Part 15 Class B, EN 55022 Limit B, EN 55024, UL-60950-1, BMSI CNS, CISPR-22/24, IEC60950-1,
VCCI, CSA C22.2, EU RoHS directive (2011/65/EC)

Operating temperature 0° to 45°C

Connectivity Native DisplayPort suggested

Single-link DisplayPort or

Dual-link DisplayPort to DVI-I adaptor available separately
