|Interface||PCI Express 3.0|
|GPU Series||NVIDIA GeForce RTX 20 Series|
|GPU||GeForce RTX 2060|
|Core Clock||OC Mode: 1395 MHz
Gaming Mode (Default): 1365 MHz
|Boost Clock||OC Mode: 1710 MHz
Gaming Mode: 1680 MHz
|Effective Memory Clock||14000 MHz|
|HDMI||2 x HDMI 2.0b|
|DisplayPort||2 x DisplayPort 1.4|
|Max Resolution||7680 x 4320|
|Virtual Reality Ready||Yes|
|Thermal Design Power||160W|
|Recommended PSU Wattage||500W|
|Power Connector||1 x 8-pin|
|Features||NVIDIA TURING: ASUS GeForce RTX graphics cards are powered by the Turing GPU architecture and the all-new RTX platform. This gives you up to 6X the performance of previous-generation graphics cards and brings the power of real-time ray tracing and AI to games.
DirectX 12: Power new visual effects and rendering techniques for more lifelike gaming.
NVIDIA Shadowplay Record and share high-quality gameplay videos, screenshots, and livestreams with your friends.
Redesigned Shroud improves cooling for multi-card configurations and chassis with limited airflow.
Dual-ball Bearing Fan with IP5X Dust Resistance is a larger, quieter, and dust resistant fan that shifts more air.
144-Hour Validation Program puts cards through a series of stringent tests to ensure reliability.
GPU Tweak II provides intuitive performance tweaking and thermal controls.
|Max GPU Length||268 mm|
|Card Dimensions (L x H)||10.54" x 4.45"|
|Slot Width||Dual Slot|
