ASUS GeForce GTX 560 1GB GDDR5 256-bit PCI Express 2.0 x16 HDCP Ready SLI Support Video Card ENGTX560 DCII TOP/2DI/1GD5
SKU:
7GC0956
Availability:
In Stock
Free shipping
$294.00
Secure checkout with:
Brand:
ASUS
Overview
| Brand | ASUS |
|---|---|
| Model | ENGTX560 TI DCII/2DI/1GD5 |
| Interface | PCI Express 2.0 x16 |
|---|
| Chipset Manufacturer | NVIDIA |
|---|---|
| GPU Series | NVIDIA GeForce GTX 500 Series |
| GPU | GeForce GTX 560 Ti (Fermi) |
| Core Clock | 830MHz |
| Shader Clock | 1660MHz |
| CUDA Cores | 384 |
| Effective Memory Clock | 4000MHz |
|---|---|
| Memory Size | 1GB |
| Memory Interface | 256-Bit |
| Memory Type | GDDR5 |
| DirectX | DirectX 11 |
|---|---|
| OpenGL | OpenGL 4.1 |
| HDMI | 1 x mini HDMI |
|---|---|
| DVI | 2 x DVI |
| RAMDAC | 400MHz |
|---|---|
| Max Resolution | D-Sub Max Resolution: 2560x1600 DVI Max Resolution: 2048x1536 |
| 3D VISION Game Ready | Yes |
| SLI Support | SLI Ready |
| Cooler | Double Fans |
| System Requirements | Up to 225W Power require |
| Power Connector | 2 x 6-Pin |
| Dual-Link DVI Supported | Yes |
| HDCP Ready | Yes |
| Features | Engine overclocked to 830MHz for faster and smoother performance Speed up heat dissipation with doubled airflow via exclusive DirectCU dual fan design Pump up graphics performance with Super Alloy Power delivering a 15% performance boost, 2.5 longer lifespan and 35 degree cooler operation Crank up 50% faster clock speeds with exclusive Voltage Tweak |
|---|
| Card Dimensions (L x H) | 10.16" x 5.12" |
|---|
